Cable Coiling & Binding
Automatic 8-Shape Cable Coiling & Tying Machine WPM-40XL
Model No. WPM-40XLPrice on request2,377 views
Specifications
- Model Number
- WPM-40XL
- Finished Product Shapes
- 8 shapes, single tying
- Wire/Cable Type
- AC/DC/USB, etc.
- Wire Outer Diameter
- ≤ 4 mm
- Winding Part Distance
- 45 - 80 mm
- Winding Length
- ≤ 3 m (depending on wire size)
- Winding Speed
- Adjustable
- Tying Outer Diameter
- ≤ 20 mm
- Wirehead Length
- 0 - 130 mm
- Wire Tail Length
- > 0 mm
- Productivity
- 1800 pcs./h (winding length = 1 m, number of turns = 3)
- Compressed Air Connection
- 0.55 - 0.65 MPa
- Power Supply
- 110, 220 V (50 - 60 Hz)
- Power
- ≤ 2000 W
- Dimension
- 1040 * 720 * 1540 mm
- Weight
- 160 kg
Fully automatic power cord/wire coil winding machine for cable wire binding, featuring automatic bonding and tying capabilities.
Model WPM-40XL
Finished product 8 shapes, single tying
Wire/cable type AC/DC/USB, etc.
Wire outer diameter ≤ 4 mm
Winding part distance 45 - 80 mm
Winding length ≤ 3 m (depending on wire size)
Winding speed Adjustable
Tying outer diameter ≤ 20 mm
Wirehead length 0 - 130 mm
Wire tail length > 0 mm
Productivity 1800 pcs. / h (winding length = 1 m, number of turns = 3)
Compressed air connection 0.55 - 0.65 MPa
Power supply 110, 220 V (50 - 60 Hz)
Power ≤ 2000 W
Dimension 1040 * 720 * 1540 mm
Weight 160 kg
Auto 8-Letter Cable Coiling Tying WPM-40XL — Demo Video
