WPM-203-B
Power Cord Crimping Machine
Automatic Power Plug Crimping Machine for Wire Harness WPM-203-E
Model No. WPM-203-EPrice on request809 views
Specifications
- Model Number
- WPM-203-E
- Size
- 1300X700X1600mm
- Weight
- 460Kg
- Power
- AC 220V 50/60HZ
- Wire Range
- 0.5～1.25mm² (2 cores wires)
- Crimping Force
- 2T
- Air Pressure
- 5～7Kgf/cm²
Automatic Connection Terminal Machine, Power Cord Plug Inserting Crimping Machine, 3 Pin Plug Crimping Machine, Power Plug Riveting Machine
Description
Automatic Connection Terminal Machine
Automatic feed, stripping, and crimp power plug can be completed once and for all.
Equipped with a protective unit on the crimp connection point and it is safe and convenient for operation.
A green hand is easy to skill for operation.
Size 1300X700X1600mm
Weight 460Kg
Power AC 220V 50/60HZ
Available wire range 0.5～1.25mm2（2 cores wires）
Crimping force 2T
Air pressure 5～7Kgf/cm2
Description
Automatic Connection Terminal Machine
Automatic feed, stripping, and crimp power plug can be completed once and for all.
Equipped with a protective unit on the crimp connection point and it is safe and convenient for operation.
A green hand is easy to skill for operation.
Size 1300X700X1600mm
Weight 460Kg
Power AC 220V 50/60HZ
Available wire range 0.5～1.25mm2（2 cores wires）
Crimping force 2T
Air pressure 5～7Kgf/cm2
Automatic Connection Terminal Machine WPM-203-E — Demo Video
