Pneumatic Inner-Outer Sheathed Cable Stripping Machine WPM-660

Multicore Cable Stripping Machine, Outer Sheath and Inner Skin Stripping Machine, Multi-Core Cable Stripping Machine, Inner and Outer Sheathed Wire Stripping Machine, Sheathed Wire Stripping Machine, Pneumatic Wire Stripping Machine.
WPM-660 inner-outer pneumatic wire stripping machine
Model： WPM-660
Stripping length：100mm Stripping length：100mm
Outer layer peeling length：8-100mm
Outer layer peeling length：3-10mm
Inner layer peeling length：2-12mm
Inner wire stripping diameter: 0.3-2M²

Electrical connection：AC 220/110V/50/60HZ
Air pressure：0.4-0.8mpa
Force：49-115KG
Machine dimenson:400*220*550mm
Weight:30kg
Weight:30kg
Function
1. Bevel design, according to somatology.
2. Dual-driving cylinder, no spring breakage.
3. Self-feeding oil and supply. A timely oil supply to the cylinder can decrease the abrasion of the interior cylinder and lengthen life.
4. Special sliding holder, balance stroke, and high peeling precision. Electric control, easy operation.
5. Adjustable structure, and wire thickness.
6. Suitable for short cables with small diameters, such as AC/DC, power wire, computer cable, electronic cable, and multi-core cable.
