Automatic Copper Brazing Machine with Robotic Arm - WPM-155
Model No. WPM-155Price on request359 views
Specifications
- Model Number
- WPM-155
- Air Pressure
- 0.5-1.0 MPA
- Voltage
- AC220V/50Hz
- Maximum Power (Main Engine)
- 3.4KW
- Power (Main Engine)
- 1.5KW
- Maximum Power (Brazing Machine)
- 20KW
- Cooling Hydraulic Pressure
- 0.2MPa
- Speed
- 8 seconds/piece
- Dimensions
- 2100mm x 900mm x 2100mm
- Floor Space
- 5020mm x 2100mm
Description Automatic Brazing Machine is the newest automatic welding machine developed by our company. This machine applies to welding all kinds of copper workpieces. The high-frequency brazing technique and robotic arm realize the welding between workpieces. It has the advantages of a wide range of applications, good effect, high efficiency, cost-saving and environmental, etc.
Specification
Air Pressure: 0.5-1.0MPA
Voltage: AC220V/50Hz
Maximum power of the main engine: 3.4KW
Power of main engine：1.5KW
Maximum power of Brazing Machine：20KW
Cooling hydraulic pressure：0.2MPa
Influent temperature： less than 40℃
Speed:8 seconds/piece
Dimension：2100mm*900mm*2100mm
Floor space：5020mm*2100mm
