Automatic Coaxial Cable Stripper Machine 6.99mm, 9 Layers WPM-6806

WPM-6806 Precision Coaxial Cable Stripping Machine - High-Speed, Multi-Layer Performance

Introduction:

Introducing the WPM-6806 Coaxial cable stripping machine, a high-performance, automatic solution designed to elevate your coaxial cable preparation process. This advanced machine is engineered as a versatile Coaxial Cable Stripping Machine, part of our comprehensive range of Coaxial Cable Strip Equipments and Coaxial Cable Stripping Machines, offering unmatched precision and efficiency. Whether you're looking for a reliable Coaxial Cable Stripper for semi-flexible and flexible coaxial wires, charging cables, or medical wires, the WPM-6806 delivers consistently smooth, conductor-safe stripping in demanding communication and medical industry applications.

Key Features for Superior Coaxial Cable Processing:

The WPM-6806 Coaxial cable stripping machine is engineered with a suite of features designed to maximize performance and user experience:

• Versatile Wire Compatibility: Specifically designed to process various types of semi-flexible and flexible coaxial cables, charging cables, and medical wires, making it an ideal solution for both communication and medical industry applications.
• Smooth and Conductor-Safe Stripping: Engineered to deliver a smooth stripping edge, ensuring no harm or damage to the conductor, crucial for maintaining signal integrity in sensitive applications.
• User-Friendly Huma-Computer Interface: Features an intuitive huma-computer interface that is easy to operate and understand, minimizing training time and maximizing operator efficiency.
• Advanced Multi-Layer Stripping: Capable of stripping up to 9 layers, allowing for complex and intricate stripping processes required for modern, multi-layered cable designs.
• Extensive Memory Function: Offers a large memory capacity that can store up to 99 sets of machining parameters, facilitating quick job changeovers and streamlining production for diverse cable types.
• Rotating Blade Head for Enhanced Stability: Employs a rotating blade head with four exquisitely designed blades. This innovative design significantly improves stripping stability and extends the lifespan of the blades, reducing maintenance costs.
• Servo Motor and Precision Motion Control: Adopts a servo motor, precision ball screw, and multi-point movement control system, ensuring stable and highly efficient working performance, contributing to consistent output quality and increased throughput.
• High-Quality, Durable Blades: Equipped with two knife blades made from imported Switzerland tungsten steel and two centering slabs also made from imported tungsten steel. These premium materials ensure exceptional sharpness, durability, and long-lasting performance.
• Automatic Wire Adjustment and Tension Control: Features a clip-wire device that automatically adjusts to the core diameter, driven by a dynamo with precise clip-tight strength process control. This ensures secure and damage-free wire handling during stripping.

Wide Range of Applications Across Key Industries:

This high-precision Coaxial Cable Stripping Machine is essential for industries that demand reliable and precise coaxial cable preparation:

• Communication Industry: Crucial for preparing coaxial cables for telecommunications, data networks, and broadcasting, ensuring high signal quality and network performance.
• Medical Industry: Ideal for processing medical wires and cables where precision and damage-free stripping are paramount for patient safety and the reliability of medical devices.
• Electronics Manufacturing: Suitable for a wide range of wire stripping needs in electronics assembly, providing consistent and accurate wire preparation for electronic components and devices.
• Aerospace and Defense: Applicable for specialized coaxial cable stripping applications within the aerospace and defense sectors where high reliability and precise connections are critical.
• Research and Development: A valuable tool for R&D labs working with advanced cable technologies, providing the precision and versatility needed for experimentation and prototyping in material science and engineering.

Technical Specifications for High-Performance Coaxial Cable Processing:

• Model: WPM-6806
• Machine Type: Automatic Coaxial Cable Stripping Machine
• Key Functions: Coaxial cable stripping machine, Coaxial Cable Stripping Machines, Coaxial Cable Stripper, Coaxial Cable Strip Equipments (Versatile, Multi-Layer Stripping)
• Max. Stripping Length: 48mm (Adjustable for various applications)
• Cutting Depth Unit: 0.01mm (Ultra-fine precision adjustment)
• Capacity: 700-1200pcs/h (Depending on wire material and complexity)
• Wire Diameter Range: 0.1-6.99mm (Broad Cable Diameter Capacity)
• Length Accuracy: ±(0.002* L) mm (High Precision Cutting Length)
• Max. Stripping Layer: 9 Layers (Complex Multi-Layer Stripping)
• Noise Level: <70dBA (Low Noise Operation)
• Display: Touch Screen (User-Friendly Interface)
• Knife Blade Material: Imports Switzerland Tungsten Steel (2 blades)
• Centering Slab Material: Imports Tungsten Steel (2 slabs)
• Clip Wire Device: Automatic Core Adjustment, Dynamo Drive, Clip-Tight Strength Process Control
• Dimensions: 600mm * 185mm * 280mm (Compact Benchtop Design)
• Weight: 24kg (Portable yet Robust)
• Power Supply: 220V/50HZ, 110V/60HZ (Selectable Voltage)
• Power Consumption: 400W
• Delivery Information: Typically 3-5 days lead time after deposit received, Port of Loading: XIAMEN/SHENZHEN

Conclusion:

Invest in the WPM-6806 Coaxial cable stripping machine to revolutionize your coaxial cable preparation. This high-performance Coaxial Cable Stripper and efficient Coaxial Cable Stripping Machines solution delivers unmatched precision, speed, and user-friendliness, making it the ultimate Coaxial Cable Stripping Machine for maximizing your production efficiency and product quality. Contact us today to learn more about how the WPM-6806 can transform your cable processing line and elevate your manufacturing capabilities!

Model	WPM-6806	WPM-8608	WPM3512	WPM-4520
Wire Diameter	0.81-6.99mm	3.0-18mm	5mm-35mm	5.0-45mm
Cutting depth	0.01mm	0.01mm	0.01mm	0.01mm
Working efficiency	700-1200PCS/H	400-800PCS/H	200-500PCS/H	200-500PCS/H
Max. stripping length	48mm	90mm	120mm	200mm
Max. stripping layer	9 layers	9 layers	9 layers	9 layers
Dimensions	600*185*280mm	720*280*350mm	1040*280*550mm	1160*280*550mm
Weight	26kg	40kg	60kg	70kg
Power supply	220V/110V/50HZ/60HZ	220V/110V/50HZ/60HZ	220V/110V/50HZ/60HZ	220V/110V/50HZ/60HZ
Power rating	400w	500w	1000w	1000w
